Open 5KVA mobile power supply 5KW alternator generator 5kva silent diesel generator

Short Description:

low cost
Since diesel is relatively inexpensive compared to regular gasoline, it is more commercially suitable for different industrial applications. The low cost of diesel fuel results in low cost energy production. Diesel-generated energy can be used for many purposes, including power generation in industrial equipment and applications. Cheap energy will also reduce production costs, which helps regulate product prices on the market.

easy to obtain
Of all fossil fuels, diesel is the most readily available in the world. It’s almost everywhere. This is especially useful if you have field offices in remote areas. Diesel generators can easily compensate for your energy needs. If you are looking for an economical energy solution, you should buy a diesel generator.

After sale value
One of the most valuable advantages of diesel generators is their high market value. Diesel generators are popular and therefore easy to sell. You can buy a new or used diesel generator for your remote office and sell it with little to no depreciation.

Send email to us

Product Detail

specification

detail exploded view

Field Of Application

Other Optional Devices

Related HOT-Selling Models

Advantages for Our Spare Parts

Quality Control

Assembly Line

Strong Packing For Export

Previous: High Performance Cummins Whole House Generator - Deutz Diesel Power Generator D G 15kVA 20kVA 30kVA 50kVA 60kVA 80kVA 100kVA 150kVA 200kVA 300kVA 400kVA 500kVA 600kVA Genset – SOROTEC

Next: Open China 10kva 11kva 12kva 10kw 220V diesel power generator

Model No		SRT6500XE	SRT7500XE	SRT8500XE
Rated frequency	(Hz)	50/60	50/60	50/60
Rated power	(kVA)	4.5/5.0	5.0/5.5	6.0/6.5
Max power	(kVA)	5.0/5.5	5.5/6.0	6.5/7.0
Rated voltage	(V)	115/230 ;120/240
Rated current	(A)	39.1/19.6	43.5/21.7	52.1/26.1
Rated current	(A)	41.7/20.8	45.8/22.9	54.2/27.1
Rated rotation speed	(rpm)	3000/3600	3000/3600	3000/3600
Pole No.		2	2	2
Phase number		Single phase
Excitation mode		Self-excitation and constant voltage(with AVR)
Power factor	(COSΦ)	1
Insulation grade		F
Engine model No		186FAE	188FAE	192FAE
Engine type		Single cylinder, in-lined, 4-stroke, air cooled, direct-injected
Bore×stroke	(mm)	86×72	88×75	92×75
Displacement	(cc)	418	456	499
Compression ratio		19.5:1	19.5:1	19.5:1
Rated power	(kW)	5.7/ 6.3	6.6 /6.9	7.6/8.6
Lubrication system		Pressure splashed
Lube oil brand		CD Grade Above or SAE 10W-30,SAE15W-40
Lube oil capacity	(L)	1.65	1.65	1.65
Starting system		X: Recoil starter E:12V Electric system
Starting motor capacity	(V-KW)	X: Without ; E:12V 0.8~1.2KW
Charging generator capacity	(V-A)	X: Without ; E:12V 3A
Battery capacity	(V-Ah)	E:12V 30Ah		E:12V 36Ah
Fuel consumption ratio	(g/kW.h)	275.1/ 281.5	275/280	275/280
Fuel type		0#(summer),-10#(winter),-20#(chilliness ) diesel
Fuel tank capacity	(L)	12.5	12.5	12.5
Packing Size(L×W×H)	(mm)	720492655	720492655	720492655
Gross weight	(kg)	E: 100	E: 105	E: 110
Loading Quantity(20”/40”)	(PCS)-MAX 25.5 TON
Loading Quantity(20”/40”)	(PCS)-MAX 25.5 TON	E: 102/255	E: 102/255	E: 102/242
